Honeycomb Wire Mesh Conveyor Belt - Metal Plate Chain Rod Flat Wire Belt - Heavy Belt

Stainless Steel Honeycomb Conveyor Belt offer a high strength-to-weight ratio wire mesh belting solution used in baking, glass industry, machining and packaging industries. The flat wire strips linked by cross rods design ensures effective performance with a positive sprocket drive mechanism.

This metal belt has a honeycomb-like structure, henced named Honeycomb Conveyor Belt, also named Flat Wire Belting due to the flat wire / strip metal and smooth surface.

Products Overview

Material: Stainless steel (also available: carbon steel, hot dipped galvanized steel for specific uses)

Processing

Manufacturing Process: Honeycomb belts are made using a series of flat metal plates / strips linked by cross rods to form a structure similar to honeycomb. These plates or strips are typically made of stainless steel for durability and resistance to high temperatures and corrosion. This design ensures stable and reliable transportation of products.

Features

Using chain drive, suitable for large and heavy-duty conveying mesh belts.

High Load Capacity: The unique honeycomb design allows for efficient handling of heavy loads.
Stability: Ensures stable transportation of items.
Durability: Made from high-quality stainless steel, these belts are resistant to wear, tear, and corrosion.
Not easy to deform: The mesh surface is strong and durable and not easy to deform.
Temperature Resistance: Suitable for high-temperature environments, making them ideal for baking, drying, and other heat-related processes.
Easy to Clean: The open design allows for easy cleaning, ensuring hygienic operations especially in food processing industries.
Smooth transfer: The chain network transmission is smooth and the transmission torque is small.
Heavy pressure handling: Flat mesh surface, and can bear heavy pressure and tension.
Good ventilation: Large open area, ideal for washing, drying, cooling, and cooking processes due to efficient drainage and air circulation.

Chains

Types: Chains can be attached to the sides of the belt for additional support and guidance.
Material: Usually made from the same stainless steel as the belt for consistency in performance and durability.

Rods

Function: Cross rods are critical in maintaining the structure of the belt, connecting the flat wires and ensuring stability.
Material: Typically made from stainless steel, although other materials can be used depending on the application.

Parts Options

Drive Components: Including sprockets and gears tailored to the specific belt design.
Custom Attachments: Such as cleats, flights, or guards to suit various conveying needs.

Major Applications

This heavy belting is widely used in annealing furnace, baking furnace, in the glass products industry, in food processing, powder metallurgy, metal heat treatment, quenching, sintering, brazing, roasting, brightening, blackening, bearings, carburizing high temperature furnace, coating drying line conveyor system, some listed as below:

Food Processing: Ideal for baking, cooking, and freezing, dehydrated vegetables, quick-frozen food single freezer pre-processing mesh belt.
High temperatuer furnace belting: Annealing furnace mesh belt, baking furnace in glass industry, powder metallurgy, metal heat treatment, quenching, sintering, brazing, etc.
Industrial Manufacturing: Used in assembly lines, product handling, and processing.
Packaging Industry: For transporting packaged goods through various stages of the packaging process.

Honeycomb Conveyor Belt Products - Types, Specifications, Case Study

Honeycomb Belt Types according to Conveying Capacities:

Standard Duty Belt:
Technical Details: Made of thinner metal plates or strips and rods for lighter applications.
Specific Application: Ideal for lightweight product transportation and processing.

Heavy Duty Belt
Technical Details: Constructed with thicker plates / strips and rods with reinforced edges.
Specific Application: Suitable for heavy loads, high-temperature environments, and abrasive conditions.

Customizable Belt
Technical Details: Designed according to specific industry needs, various widths, materials, and additional attachments.
Specific Application: Tailored to unique requirements of different industries, ensuring optimal performance for specialized tasks.

Customized Products and Services

We supply customizable honeycomb belt options to meet specific operational needs. The selection of the right dimensions is crucial for optimal performance and longevity of the conveyor belt in its intended application. Welcome contact us for recommended solution for your specific requirements.

Flat Strip Honeycomb Mesh Conveyor Belts SS 316

Flat flexible belts made from round edge flat strip steel, featuring smooth level conveying surface.
Belts available in three different mesh openings, clinched edges available, widths from 4 1/2 inches to 15 feet.
Materials: Stainless steel AISI 316 grade, Galvanized Steel high Carbon Steel upon request for specific requirement.

Flat Wire Honeycomb Conveyor Belt - Galvanized

Type: Flat Wire Conveyor Belt
SD & HD flat wire belt 1” x 1”
Belt width 71” and length 300 feet.
Material: Galvanized Steel

Specification:
Pin diameter: 11 gauge min. 6 gauge recommended
Height of flat Steel strip: 3.75” min., or 9.5mm
Flat Steel thickness: 0.0625 min., ” or 1.58 mm
Exported to USA

Honeycomb Conveyor Belt in Stainless Steel - 500 x 500mm

Stainless steel conveyor chain belt for India customers

SS Conveyor belt honeycomb flat type
Size:
1.2mm (ss wire swg) x 500mm mesh belt width x length 15m
1.8m (width) x 70m (Length)
Metal plate opening: 500 x 500mm

Used to replace following conveyor belt:

1"x1" Mesh Honeycomb Belt
 Replace following honeycomb belt with 1"x1" Mesh Honeycomb Belt Clinched Edge:

Honeycomb Wire Mesh Belts - AISI 304 Grade
Honeycomb Belts - Waved honeycomb metalfret in different
pitches.
Shipping to Italy
Pitches 13,7 x 14,7 mm
Metal fret 9,5 x1,2mm
Length: 4m
Width: Various
Belt in AISI 304

Honeycomb Belt design:

PDF 1

Flat Wire Belt 13,7 x 14,7 mm with metal fret 9,5x1,2mm and crossrod Ø 3mm

Sprocket position:
First driver sprocket: 3rd honeycomb

First idle sprocket:
Second honeycomb



PDF2

Design:

Honeycomb Wire Mesh Belt with pitches 22 x 30,6 mm with metal fret 12,5x1,5mm and crossrod Ø 4mm

Sprocket position:
First driver sprocket: 3rd honeycomb

First idle sprocket:
Second honeycomb

Honeycomb Wire Mesh Conveyor Belt

Replace existing conveyor belt with a modular honeycomb belt in stainless steel, with sprockets:
Customer needs to replace following Galvanised Steel Honeycomb Belt with reinforcement, with Modular Stainless Steel Honeycomb Belt:
