Welcome to Hehua Stainless Steel Wire Mesh Factory!

Our primary focus is the manufacture of woven wire mesh and cloth, especially in stainless steel mesh, for filter, mining, architectural and a wide range of industrial uses. Stainless Steel Wire Mesh & Cloth, as an ideal filter medium, stands out when solutions for precise filtration and excellent corrosion resistance are needed. It excels in giving problem-free screening and is easily cleanable with excellent durability. The space wire weaves in square opening or rectangular openings can be woven down to a fineness of 5 micron aperture, also there are many combinations of filter weaves with retention in the micron range.

In addition to coarse and fine stainless steel wire mesh, we also supply woven wire mesh filter cloth in other metals, like brass, copper, nickel, silver even gold.

Hehua Stainless Steel Wire Mesh Cloth made from choice wires are used for separation of solids and clear filtration of liquids, or in water treatment. Mostly used weaving patterns are plain weave, twill weave and Dutch weave (Plain Dutch weave and Twilled Dutch Weave) while we still use other methods like five- heddle and reverse Dutch.

Plain woven stainless steel wire mesh is the most commonly used style of products. Every second wire is woven in, warp and weft wires run over and under each other alternately and interlock. Plain weave wire meshes guarantee optimum accuracy of apertures or filter pores. Plain weave wire cloth use wires that are thinner than the corresponding apertures.

Twilled woven wire mesh is suitable for where increased wire thickness is required in relation to the aperture size. At least two wires are woven in pairs, subsequently displacing a single wire. Mesh stability is controlled by a combination of aperture size and wire strength, and displays a slight diagonal trend. Twill Weave allows a thicker wire and is suitable for heavy meshes. The wire position of twill woven wire mesh is less stable compared with plain weave.

Plain Dutch Weave is similar to plain weave, while the warp wires are thicker and lie closer to each other. This type of stainless steel woven wire mesh is mainly used as industrial filter cloth and apparatus of separation.

Twill Dutch Weave is a combination of the Hollander Weave and the twill weave. This type enables a strong wire cloth with super fine filtration. Twilled Dutch woven wire cloth in stainless steel is ideal for fine filtration.

Crimped woven wire mesh is used for sifting and sieving, while fine crimped woven mesh is also used as decorative mesh fabrics.
Creative woven stainless steel mesh of wire and cable is popularly used in architecture designs.

We have added to our product category quality stainless steel conveyor belt mesh products suitable for all kinds of conveying systems in mine, metallugy, food stuff, furnace and oven conveying, washing, baking and other uses.

Pdf About SS Wire Mesh

News & Events

SUS 304 Stainless Steel Thickened Filter Mesh Sheet for Grain Sieves

Stainless Steel Mesh Glove for Cut Resistant Safety Working

SS 201, 304 Stainless Steel Wire Shelving and Chrome Wire Shelving

304 316L Stainless Steel Ring Mesh

SS 304 Chain Link Fence and SS316 Chain Link Fence provide superior corrosion resistance

Stainless steel 316 Wire Rope Mesh is popularly used as zoo fencing.

Scaleless Blue Oil Tempere fre Steel Mattress Frame Wire for Flat Frame Spring Pocket Mattress

Stainless steel mesh for facade cladding project

316L ss mesh or 904L ss mesh?

How to choose types of disc filter screens according to applications：Particle filtration, extruder, gas and fuel filter or other specific uses?

Stainless Steel Wire Mesh, crimped mesh, coarse openings

Welded stainless steel 316 wire mesh

Stainless Steel Mesh SS316 Filter Wire 0.5mm, 10 Micron to 400 Micron

S.S. 304 Wire Mesh, 20-200 Mesh, Wire 0.38 to 0.05mm

Stainless Steel Wire Mesh Technical Parameters

Stainless steel filter mesh

How to clean Stainless steel mesh filter?

How to choose stainless steel screens

Keep Wire Mesh Clean and Use it for a Long Service Life

How to maintain stainless steel mesh

Typical features of stainless steel wire mesh

How to identify the material quality of mesh

How to deal with rust stainless steel mesh

Learn about our new stainless steel products: ss gratings, expanded metal, filter baskets and other materials

More »

Black Powder Coated 304 Stainless Steel Wire Mesh

Used for Insect Screen and Window Screening Material. PVC or Epoxy powder coated into black, grey or custom colors. The powder coated stainless mesh screen offers good permeation and air flow. It has high impact resistance and high fire resistance, easy washing and suitable for replacement screen of windows and doors against flies and pets.

Learn more.

Stainless Steel Mesh Diffusers

Stainless mesh ss grade is made into disc type diffusers of various diameters.
Hole: Square opening
Layer: single or double
Edge and surface: Deburred, break sharp edges
Application: For vent / air flow

Learn more.

Hexagonal Mesh
Lining material for reactors and regenerators
Punched and assemblyed
Material: AISI 304 SS
Mesh: 19mm (3/4") x 25mm (1") thickness

Learn more.
